STEP 1: Acquire existing as-built documentation. … STEP 2: Field verification. … STEP 3: Loading Information. … STEP 4: Run a Short Circuit Study. … STEP 5: Selective coordination. … STEP 6: Arc Flash Evaluation. … STEP 7: System Evaluation.

Who can conduct an arc flash assessment?

The short circuit study determines if all equipment is within OSHA standard 1910.303 (b)(4). An Arc Flash Study / Analysis should only be performed by experienced and qualified electrical engineers knowledgeable in power system engineering, IEEE 1584, NFPA 70E, short circuit, device coordination and arc flash studies.

What are the three hazards of arc flash?

The hazards resulting from an arc flash incident include burns, extreme heat and fire, flying objects, molten metal, and blast pressure or sound blast. Arc flashes are often violent, and when a human is near the arc flash, serious injury or even death may occur. Arc flashes can be caused by many things, including: Dust.

What three factors are determine in an arc flash risk assessment?

Three factors determine the severity of an arc flash injury: Proximity of the worker to the hazard , Temperature and Time for the circuit to break. Because of the violent nature of an arc flash exposure, when an employee is injured, the injury can be very serious and can even result in death.

How often are arc flash assessments required?

An arc flash risk assessment should be reviewed every five years, or any time modifications are made to the facility that can effect the outcome of the study. Major or sometimes minor variations such as fuse type or breaker setting adjustments can have a huge impact on personal safety.

What is arc flash inspection?

An Arc Flash Assessment / Analysis is a study of the facility’s power system to determine the incident energy available at specific electrical devices that employees would be exposed to while “interacting with” the electrical equipment at the facility.

What is arc flash analysis?

An arc flash hazard analysis or risk assessment is a study conducted by a trained safety expert to evaluate electrical equipment and power systems in order to predict the potential for or incident energy of an arc flash.

How are arc flash boundaries typically determined?

The arc flash boundary is calculated to 1.2 calories/cm2 of incident energy. That’s the distance where a worker without appropriate PPE would receive second-degree burns. Sometimes this boundary is the furthest one from the exposed equipment, other times the limited approach boundary is the furthest out.

What is an arc flash hazard assessment?

An Arc-Flash Hazard Assessment determines the degree to which a worker may be exposed to potential Arc-Flash Hazards and what kind of Personal Protective Equipment (PPE) is required to protect workers from the heat, light, and blast associated with an Arc-Flash accident.

What is HRC level?

The risk levels are from 1 to 4; HRC level 1 is low risk and HRC 4 is the highest and most dangerous risk level. Level 0 is little to no risk and Level 4 is extreme risk. Which leads to the question what is an HRC? An HRC level is determined by the minimum amount of calories per square centimeter (ATPV or Cal/cm2).

Article first time published on

What is required on arc flash label?

At a minimum, these labels must contain the nominal system voltage, the arc flash boundary, and at least one of the following: the available incident energy and the corresponding working distance or the arc flash PPE category found in the PPE category tables, the minimum arc rating of clothing, or the site-specific …

How long does it take to do an arc flash study?

Completing an arc flash study may take about four to six weeks depending on the size of the facility. The governing standard for performing the study is the Institute of Electrical and Electronics Engineers (IEEE) 1584.

Who should perform a shock and flash hazard assessment?

To determine shock hazard, a licensed electrical engineer will perform either a calculation or use Table 130.2(C) of NFPA 70E. NFPA Definition: A Flash Hazard Analysis shall be done in order to protect personnel from the possibility of being injured by an arc flash.

At what voltage is arc flash PPE required?

Each piece of equipment operating at 50 volts or more and not put into a deenergized state must be evaluated for arc flash and shock protection.

How do you read an arc flash study?

1. #1: WARNING. At the top of the label is the warning label. …
2. #2: Working Distance. …
3. #3 Incident Energy. …
4. #5 Shock Hazard when cover is removed. …
5. #6 Limited approach boundary. …
6. #7 Restricted approach boundary. …
7. #8 Glove Class.

Is arc flash required by OSHA?

OSHA does not have a specific requirement mandating that employers have arc flash studies conducted within their workplaces. However, there are a number of OSHA requirements that are a bit broader in terms of protecting workers from electrical hazards.

What are the steps in order of testing a circuit and protecting from arc flash?

1. STEP 1: Acquire existing as-built documentation. …
2. STEP 2: Field verification. …
3. STEP 3: Loading Information. …
4. STEP 4: Run a Short Circuit Study. …
5. STEP 5: Selective coordination. …
6. STEP 6: Arc Flash Evaluation. …
7. STEP 7: System Evaluation.

How do you find arcing distance?

1. Divide the chord length by double the radius.
2. Find the inverse sine of the result (in radians).
3. Double the result of the inverse sine to get the central angle in radians.
4. Once you have the central angle in radians, multiply it by the radius to get the arc length.

What are the 3 approach boundaries?

Under NFPA 70E, there are three boundaries that are observed—limited approach, restricted approach, (the shock protection boundaries) and arc flash boundary.

What is Category 2 arc flash?

In PPE CAT 2, workers need the following clothing: Required Clothing: Arc Rated Long Sleeve Shirt and Pants or Arc Rated Coverall with minimum arc rating of 8 cal/cm. 2. Required AR Face and Head Protection: Arc Rated Arc Flash Suit Hood or AR Face Shield, Sock Hood/Balaclava with minimum arc rating of 8 cal/cm. 2.

What is cal cm2 mean?

The ATPV is measured in cal/cm2, and it’s defined as the maximum incident heat energy that a fabric can absorb and lessen the injury to a 2nd degree burn. If the worker is exposed to a potential incident heat energy level of less than 4.0 cal/cm2, the proper ATPV clothing system is 4 cal/cm2.

Do transformers need arc flash labels?

Do you post arc flash labels on transformers? This was an interesting question since transformers are not part of the “such as” list of equipment requiring labels in NFPA 70E. However, sometimes people will access the bushings or remove covers from dry-type transformers.

What is incident energy analysis?

Incident energy is a measure of thermal energy at a working distance from an arc fault. … Incident energy analysis is required for selecting arc rated Personal Protective Equipment (PPE) when work is performing at or near a potential source of an arc flash.

Is arc flash study same as short circuit study?

Unlike short circuit studies where we are concerned with the maximum available fault current with arc-flash studies we are really concerned with all possible available fault currents. In many cases the highest incident energy levels are produced by the scenario that produces the lowest available fault current.

What is arc flash compliance?

Arc Flash compliance is essentially governed by OSHA although their regulations do not specifically address arc flash and arc blast as hazards in the workplace, they can and will issue citations for workplaces not addressing these hazards.

At what voltage is arc flash a concern?

Most 400 V and above electrical services have sufficient capacity to cause an arc flash hazard. Medium-voltage equipment (above 600 V) is higher potential and therefore a higher risk for an arc flash hazard.

Can 240 volts arc flash?

Results suggest that 240 V single-phase panels and equipment common in residential and light commercial applications may be at very low risk of yielding arc flash burn-related injuries.
