(32)Write a Review. See More Paint Supplies. Learn More. This Airless Paint Spray Tip is ideal for enamels, primers, interior, and exterior paints.

What is 515 spray tip used for?

For example, a 515 tip will spray a 10-inch-wide fan and have a 15-thousandths of an inch orifice. It’s the combination of fan-width and orifice-size that determines how thick of a coating you’ll spray.

Can you spray stain with a 515 tip?

Fill your Wagner paint sprayer with your deck stain. … Note: The Control Pro 130 comes with a 515 spray tip that is great for latex paint. If you’re applying stain, you’ll need a 313 HEA spray tip for stains (sold separately) or 211 HEA spray tip for sealers (sold separately).

What size is a Graco 515 tip?

Graco TrueAirless 515 0.015-in Hole 0.65-in Length Paint Sprayer Tip.

What is a 517 spray tip used for?

The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.

What's the best spray tip for cabinets?

When spraying water-based enamel and satin finish paint, it’s best to use a 311 spray tip as it will deliver a 6-inch spray fan that is perfect for cabinets and smaller doors.

What is a 311 spray tip used for?

The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC®) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.

What is a 519 spray tip used for?

Achieve greater control and less overspray on different surfaces with a wide range of coatings, from stains to exterior paints. 10 inch spray pattern ideal for larger surfaces such as houses/buildings, walls and ceilings.

What is a 313 tip used for?

Product Description. The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.

What is a 513 spray tip used for?

The Reverse-A-Clean (RAC) 513 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 513 SwitchTip has a 0.013 inch orifice and produces a 10 to 12 inch fan. Reverse the SwitchTip to easily clear clogs.

Article first time published on

What size tip should I use to spray primer?

A general rule of thumb is: Heavy-bodied primers and primer surfacers work best when you use a nozzle size of 1.7 to 2.2. Basecoats should be sprayed with a 1.4 to 1.6 nozzle.

What is the best spray tip for trim?

Trim and Doors A blue 311 tip, or a green 310, are both fine for doors and trim, but the green 310 is what I use the most for that. The six-inch fan is wide enough to cover most base board and door frames perfectly. I use this size to spray paint cabinet doors and gutters too.

What is a 619 spray tip used for?

The 619 HEA tip will spray latex paint and heavy primers with 55% less overspray. The 12-14 in. spray pattern and soft feathered edges make this an ideal tip for high production exterior painting and priming applications.

What is a 211 spray tip used for?

The 211 spray tip is used to work with light lacquers and spray more accurately. For example, to paint beams and window frames. To paint larger surfaces, such as ceilings or tables, it would be more appropriate to use a 411 spray tip with lacquers or paints / interior materials.

What is a 210 spray tip used for?

Fine finish spray tips are used for cabinetry, furniture and interior trim work (for a smooth fine finish) example Graco FF LP spray tips: 210 or 310. Low pressure tips are used primarily for spraying with pressures between 55 to 76 bar (800 to 1100 psi).

What is a 413 spray tip used for?

The Reverse-A-Clean (RAC) 413 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 413 SwitchTip has a 0.013 inch orifice and produces an 8 to 10 inch fan. Reverse the SwitchTip to easily clear clogs.

What is a 315 spray tip used for?

The 315 tip is ideal for fence picket priming and painting. The 6” fan pattern minimizes overspray when spraying pickets.

Do you spray ceilings or walls first?

Spray the walls before the ceiling. Allow the wall paint to fully dry, cover the walls with tape and plastic, and spray the ceiling. Masking walls is a lot easier than masking a ceiling upside down if you were to spray the ceiling before the walls.

Why does my airless paint sprayer leaving streaks?

Answer: Streaks in the spray pattern, especially heavy bands at the outside edge, indicates low pressure at the tip. … Using a tip that is larger than the maximum size or a tip that is worn larger will cause low pressure. The tip should also be the proper size for the type of material being sprayed.

How long does a Graco spray tip last?

A Little About Spray Tip Wear Graco tips should last anywhere from 15-135 gallons when spraying latex. They may last longer with oils and stains and may last up to a few hundred gallons if spraying a thin water like material with no grit.

What is a 310 spray tip used for?

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 310 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 6 to 8 inch fan pattern and a 0.010 inch orifice, ideal for thin materials. Reverse the SwitchTip to easily clear clogs.

Are LVLP spray guns any good?

An LVLP spray gun is a great option if you want to have low air consumption and use a lower strength air compressor, saving yourself some money and allowing you to jump into the world of DIY painting, or even semi-professional paint jobs quickly and cheaply.

What is a .017 spray tip?

017 inch Max. This means you can use any tip that ends in 17 or lower. C: Kind of material you are spraying ( Example latex primer, or oil base stain. ) Thinner materials like oil based stains don’t need a large orifice to spray, while thicker material like latex ceiling paint will clog a smaller orifice.

Is spray painting walls easy?

Using a powered paint sprayer is a quick and efficient way to paint a room. The preparation time might feel longer, but the short time it takes to apply the paint quickly makes up for this.

What tips fit Krause and Becker?

The Krause and Becker Airless Paint Sprayer comes with a 517 tip, but we discovered that this airless paint sprayer does a great job with a fine finish tip as well.

Do Graco tips fit Avanti?

This AVANTI® 519 Paint Spray Tip is easy to use, easy to clean. … Fits AVANTI® and BAUER™ airless paint sprayers and most major competitors including GRACO and TITAN.

What size tip comes with Graco Project Painter Plus?

The Project Painter Plus includes a “515” spray tip, which is great for painting large surfaces with thicker paints, but you’ll want to check the matrix (or the back of your paint can) to determine the proper tip for your job.

What do the numbers on spray nozzles mean?

Most companies identify their flat-fan nozzles with a four or five digit number (Figure 2). The first numbers are the spray angle and the other numbers signify the discharge rate at rated pressure. For example, an 8005 has an 80 degree spray angle and will apply 0.5 gallons per minute (GPM) at rated pressure of 40 psi.

Can you spray primer with a 1.4 tip?

You are partially right my friend! a 1.4 would be ok to spray etch primer and sealer, as it is thinner, way thinner than primer. Primer is very thick and a 1.7 would be the minimum to spray it with.

Can you spray primer with a 1.3 tip?

For the spraying of the entire car, a 1.3mm nozzle is recommended. The 1.4mm tip is ideal for primers and metal coatings because the droplet size allows the particles to be oriented automatically, thereby eliminating streaks and spots.

What is the best tip size for spraying lacquer?

The best spray tip for lacquers is usually in the range of 1.3mm, but if you are using an HVLP system consisting of a motor of fewer than three stages you can opt for a 1.5mm tip.
