Polar Solvent: In fire fighting, any flammable liquid which destroys regular foams. Polar solvents aggressively attack the bubble by mixing with the water in the bubble structure. Polar solvents require special foam agents and mix ratios. Examples: esters, ethers, alcohols, aldehydes and keytones.

What is polar solvent fuel?

Polar solvents are products of distillation or products that have been synthetically produced. Polar solvent fuels are miscible, that is they will mix with water. Polar fuels have a varying attraction for water. For example, acetone has a stronger affinity for water than does rubbing alcohol.

What is a hydrocarbon fire?

Hydrocarbon Fire (HF) – Hydrocarbon fires are caused by combustible liquid such as oil and gas. Carbon and hydrogen make up hydrocarbons and they do not have affinity for H2O (water). Some examples are petrol, diesel, benzene and kerosene. … By comparison to a cellulosic fire, the radiation value is 160 kW/m2.

What is the fire fighting foam called?

Aqueous film forming foam (AFFF, or alcohol resistant AR-AFFF) is a highly effective foam used for fighting high-hazard flammable liquid fires. AFFF is usually created by combining foaming agents with fluorinated surfactants.

What is Class B fire caused by?

Class B – fires involving flammable liquids such as petrol, diesel or oils.

Is high expansion foam to fight a fire on deck?

If we use high expansion foam for deck fires, the foam will fly with the wind and will not be able to extinguish the fire. For this reason, for deck fires low expansion foam is used. On tankers, it will always be low expansion foam for fires of the cargo area.

Is diesel a polar solvent?

Gasoline and diesel fuels, on the other hand, are not polar compounds and are immiscible in water.

What foams Cannot be used with fog nozzles?

Fluoroprotein foams are a derivative of protein foams. Fluoroprotein foams have fluorochemical surfactants added. They are intended for use on hydrocarbon fuels and selected oxygenated fuels. They must be properly aspirated and should not be used with non-air aspirating fog nozzles.

Is PFAS still used in fire fighting foam?

At the eleventh hour, FAA issued a classic DC doublespeak “CertAlert” to airports announcing that the firefighting foam standard that applies to airports no longer requires the use of fluorinated chemicals (i.e. PFAS).

Why is PFAS used in fire fighting foam?

AFFF are water-based fire-fighting foam products used to suppress flammable liquid fires. Per- and poly-fluoroalkyl substances, also known as PFAS are the key components in a majority of AFFF. This class of chemical substances include perfluorooctane sulfonate (PFOS) and perfluorooctanoic acid (PFOA).

Article first time published on

What is a cellulosic fire?

Cellulosic fires: These are fires characterized by the burning of cellulosic products such as wood, paper, furnishings, etc. They have a relatively slow rate of temperature rise with heat fluxes of typically 100 kW/m2.

What is pool fire and jet fire?

The first is a pool fire and this occurs when a flammable liquid leaks from a vessel or pipeline to form a fluid reservoir, which then ignites. The second, and potentially more dangerous type, is a jet fire which can happen following the rupture of a pressurised vessel and/or gas line.

What is metal fire?

Generally, metal fires are a hazard when the metal is in the form of sawdust, machine shavings or other metal “fines”, which combust more rapidly than larger blocks due to their increased surface area. Metal fires can be ignited by the same ignition sources that would start other common fires.

What is class F fire extinguished?

To extinguish a Class F fire, you need a wet chemical fire extinguisher. All other types of fire extinguisher are unsuitable for these types of fires. The process works like this: when the fire is sprayed, a layer is formed on top of the burning oil, which prevents oxygen from reaching and worsening the fire.

What is in Class C fire extinguisher?

These Class C fire extinguishers may contain monoammonium phosphate, potassium bicarbonate, or potassium chloride, all of which are suitable for putting out Class C fires. Fire extinguishers of any type can only work to extinguish a fire when used properly.

What is black fire extinguisher used for?

Black (Carbon Dioxide (CO2) Extinguishers) Black labelled fire extinguishers are CO2 fire suppressers, and they are primarily used for electrical fires. They are also used in computer server rooms. They can also be used in Class B fire types.

Is paint thinner polar?

This is because water is polar whilst paint thinner is non-polar. When the iodine (non-polar) was added to the test tube, it reacted solely with the paint thinner because “like dissolves like”.

Is alcohol a polar molecule?

Alcohols are polar, since they have oxygen-hydrogen bonds, which allow alcohol molecules to attract each other through hydrogen bonds. Since oxygen atoms are much more electronegative than hydrogen atoms, the oxygen-hydrogen bond is especially polar.

Is hydrocarbon a polar solvent?

The C-C and C-H bonds in hydrocarbon molecules, such as ethane, C2H6, are not significantly polar, so hydrocarbons are non-polar molecular substances and hydrocarbon polymers like polyethylene or polypropylene are non-polar also.

What does the Colour blue on a fire extinguisher indicate?

There are five fire extinguisher colours: Red – Water (both spray and mist) Blue – Dry powder. Cream – Foam.

How many fireman's outfits do tankers carry?

In addition, two fireman’s outfits shall be provided for tankers.

What is the difference between low expansion foam and high expansion foam?

LOW EXPANSION FOAM: Foam aerated to an expansion ratio of between 2 to 1 and 20 to 1. MEDIUM EXPANSION FOAM: Expansion ratio between 20 to 1 and 200 to 1. HIGH EXPANSION FOAM: Expansion ratio above 200 to 1. … From the above, it becomes obvious that a 3% foam concentrate is twice as concentrated as a 6% foam concentrate.

Is Fire Fighting Foam toxic?

Firefighting foam contains numerous toxic chemicals known as “forever chemicals.” These chemicals do not break down quickly and stay around for a long time. They are linked to a variety of chronic and disabling illnesses and conditions, especially cancers.

What does PFAS do to humans?

A growing body of science has found that there are potential adverse health impacts associated with PFAS exposure, including liver damage, thyroid disease, decreased fertility, high cholesterol, obesity, hormone suppression and cancer.

Do ABC fire extinguishers have PFAS?

There are two major types of firefighting foam, Class A and Class B. Class A foams are used to extinguish fires caused by wood, paper, and brush. Fluorinated foams contain PFAS, and fluorine-free foams do not. …

What is Afff made of?

Synthetic foams Aqueous film forming foams (AFFF) are water-based and frequently contain hydrocarbon-based surfactant such as sodium alkyl sulfate, and fluorosurfactant, such as fluorotelomers, perfluorooctanoic acid (PFOA), or perfluorooctanesulfonic acid (PFOS).

What percentage of finished foam is water?

In other words, depending on the type of foam, or the type of fuel, foam concentrate is designed to be mixed with 99 parts water to 1 part concentrate (1 % foam concentrate), 97 parts water to 3 parts (3% foam concentrate), or 94 parts water to 6 parts concentrate (6% foam concentrate).

What is 3% foam used for?

These formulations are also available for use at 3% on both hydrocarbons and polar solvent fuels. Class A foams may be used as a firefighting agent or as a fire barrier. When used as a wetting agent, the concentrate lowers the surface tension of the water, allowing better penetration into deep seated fires.

Is Teflon a PFAS?

In 1946, DuPont introduced Teflon to the world, changing millions of people’s lives – and polluting their bodies. Today, the family of compounds including Teflon, commonly called PFAS, is found not only in pots and pans but also in the blood of people around the world, including 99 percent of Americans.

Are PFAS banned in Australia?

PFAS in South Australia South Australia was the first state to ban all fluorinated (PFAS-containing) fire-fighting foams, which have been a key source of PFAS contamination around the world due to inadvertent releases to the environment during fire-fighting responses.

Do all AFFF contain PFAS?

All AFFF products contain PFAS. This applies to foams used in the past and those being sold today. Foam currently in stock or new foam that is labeled as AFFF or AR-AFFF, contains perfluoroalkyl or polyfluoroalkyl substances, or both, as active ingredients (DOD 2018; Darwin 2004).
