What Does P0171 Mean For Your Ford? Combustion engines run most efficiently when they maintain an air-fuel mixture ratio of 14.7 parts air to 1 part fuel. When there are more than 14.7 parts air to 1 part fuel in the air-fuel mixture, a lean condition exists and code P0171 is triggered.

How do I fix code P0171?

1. Replacing the fuel pump.
2. Replacing the fuel filter.
3. Replacing the fuel pressure regulator.
4. Replacing the powertrain control module.
5. Replacing one or more injectors.
6. Replacing one or more oxygen sensors.
7. Replacing the mass air flow sensor.
8. Repairing a vacuum leak.

How much does it cost to fix a P0171 code?

What is the cost to resolve a P0171 code? This code will require a diagnostic check, which will run about $100 depending on the time it takes to find the issue. As there is a laundry list of reasons why the engine runs lean, the average price per repair will vary greatly.

Is it OK to drive with P0171 code?

It is okay to drive a vehicle with P0171 for a short period of time, but driving with this code for an extended period of time can overheat the engine and cause internal engine damage.

What causes P0171 and P0174 codes Ford?

COMMON CAUSE: A DIRTY MAF SENSOR One of the most common causes of Ford P0171 and P0174 lean codes is a dirty mass airflow (MAF) sensor. … The MAF sensor can also be contaminated by fuel vapors that back up through the intake manifold and throttle body when the engine is shut off.

How do you fix lean air/fuel mixture?

Vacuum leak: Vacuum leaks can cause a lean fuel mixture. Inspecting and replacing damaged vacuum lines with good hoses and clamps can solve a lean problem. Clogged fuel filter: clogged fuel filters will limit the amount of fuel requires by the engine.

Can bad spark plugs cause P0171?

Not likely. A P0171 ( too lean, Bank 1 ) code is most often caused by a vacuum leak downstream from the MAF sensor or a malfunctioning MAF sensor. Bad spark plugs could actually cause the opposite code ( too rich, bank 1).

What causes P0171?

The most common causes of the P0171 code are vacuum or intake leaks, low fuel pressure, faulty PCV valve, or a faulty MAF sensor. Other things can also cause the P0171 code.

Can a dirty air filter cause a P0171 code?

If the filter is clogged or excessively dirty, this is enough to impede or restrict the air flow, hence resulting in a lean running condition. Besides a dirty air filter, the P0171 code can also be blamed on a dirty or faulty MAF sensor and a clogged fuel filter.

Can an exhaust leak cause a P0171 code?

An exhaust leak upstream of the O2 is kind of unlikely to cause a p0171, as it would have to be siphoning ‘clean’ air in via venturi effect. A head gasket leak or cracked head will allow the coolant to be burned.

Article first time published on

What is P0171 system Too Lean Bank 1?

The OBDII trouble code P0171 – System Too Lean (Bank 1) means that the engine air-fuel mixture is too lean, or there is too much air and too little fuel. Driving a car with the code P0171 can cause more damage to the engine over time, as when the engine runs lean, the combustion temperature is higher.

Can EGR valve cause lean condition?

Unwanted EGR flow at idle, even in very small amounts, causes a type of rough running that may easily be misidentified as a lean condition (somewhat more likely in MAP-based fuel systems).

What is the code P1131 Ford?

In a nutshell, Error Code P1131 on your Ford vehicle indicates a trouble in your O2 sensor. The O2 sensor’s job is to measure the amount of oxygen in the exhaust, and determine whether the air fuel ratio in the cylinder is too rich or too lean.

Will a vacuum leak cause a lean condition?

A vacuum leak will cause the engine to run lean. In other words, there will be more air entering the engine than is needed to balance out the air/fuel ratio. … A rough running engine. Too fast of an idle.

Can a vacuum leak cause a car to run lean?

If your vehicle has an engine vacuum leak, the air-fuel ratio in your engine will be higher than 14.7:1, also called a “lean” mixture. This ratio means that there is too much air in your engine, and as a result, the engine will run poorly or not at all.

What side of the engine is Bank 1?

Bank 1 and bank 2 simply refer to either side of the engine. Bank 1 is on the side with cylinder 1. Bank 2 is the side with cylinder 2. Most commonly Bank 1 is towards the front of the car if it has a transverse engine.

Can bad TPS cause lean condition?

A short in the sensor, for instance, will produce the “always-open” error, resulting in an overly rich fuel mixture. If the sensor circuit remains continuously open, the computer will interpret this as an “always-closed” signal and create an overly lean fuel mixture.

What would make my car run lean?

Your engine runs lean if your air-to-fuel mixture is too light – this means that the fuel in your ignition chamber is being igniting with too much air or too little fuel. … Your engine running lean is always a symptom of another problem – it could be a dirty MAF sensor, a damaged oxygen sensor, or damaged fuel injectors.

Can a bad O2 sensor cause a lean code?

A P0171 or P0174 lean code with an O2 sensor reading lean all the time mean — well, several things. The real problem may not be a bad O2 sensor, but possibly be an engine vacuum leak, low fuel pressure or dirty fuel injectors that are causing the engine run lean. … Like us, O2 sensors slow down as they age.

Where is the MAF sensor located?

MAF sensors are located between the air filter and the throttle body and are responsible for measuring the amount of air entering the engine. Most vehicles have a hot wire MAF sensor.

Can a map sensor cause a P0171 code?

Low manifold vacuum can cause a P0171 code and a P0174 code Sensor issues—If the MAF or MAP sensors aren’t working properly or the oxygen sensors are worn or contaminated, the computer will miscalculate the air/fuel mixture.

Can a hole in the muffler cause lean condition?

As such, the sensor will interpret it as a lean condition, assuming not enough fuel was present to burn the stowaway oxygen. It’s no secret that an exhaust leak negatively impacts wideband accuracy, or that it will skew readings lean, but how big of a hole would cause a significant reading change remained untested.

How is po420 code diagnosis?

1. Scan your vehicle to verify P0420 is the only code present. …
2. Examine the exhaust system for damage and leaks. …
3. With the vehicle running and at normal operating temperature, use the digital multimeter to check the voltage reading of the downstream O2 sensor.

What causes P0171 and P0174 codes?

Code P0171 indicates Bank 1 of the engine has a lean fuel mixture. P0174 indicates Bank 2 of the engine has a lean fuel mixture. … P0171 is triggered by the engine bank 1 “upstream” oxygen sensor and P0174 is triggered by the engine bank 2 “upstream” oxygen sensor.

Can a bad PCV valve cause a lean code?

Ford Expedition lean codes could caused by a leaky PCV hose. If a car has a check engine light on and has P0171 and P0174 codes stored, the most likely cause is a vacuum leak. … If both of these codes are stored this means that both banks of the engine have excessive oxygen in the exhaust.

Which side is Bank 1 on Ford?

The Ford F-150’s Bank 1 O2 sensor should be found on the right or passenger side of the truck under the vehicle, near the engine before the catalytic converter. Look 12 inches above the converter, near the firewall to access it.

Is it bad for an engine to run lean?

In combustion engines, “running lean” goes beyond using gas efficiently. In effect, that status makes the engine perform with less gasoline than it needs to operate properly, and it increase the amount of friction between the engine’s moving parts. Running lean can damage an engine.

Is Bank 1 upstream or downstream?

Bank 1 Sensor 1 means Upstream Right/Rear;Bank 2 Sensor 1 means Upstream Left/Front;Bank 1 Sensor 2 means Downstream Right/Rear;Bank 2 Sensor 2 means Downstream Left/Front.

Is it better to run lean or rich?

TLDR – running just a little lean could improve fuel economy and give extra power. However, run too lean and you risk engine failure because the engine runs too hot. Whereas running rich can waste fuel and increase pollution but will not damage the engine.

What are the symptoms of a lean fuel mixture?

A lean fuel mixture (too little fuel for the amount of air in the cylinder) can cause an engine to have a surge or miss at idle and part throttle, stumble on acceleration, engine overheating, cause a lack of power, and create possible engine failure from the lean air/fuel mixture.

How can I tell if my EGR valve is bad?

1. Your engine has a rough idle. …
2. Your car has poor performance. …
3. You have increased fuel consumption. …
4. Your car frequently stalls when idling. …
5. You can smell fuel. …
6. Your engine management light stays on. …
7. Your car produces more emissions. …
8. You hear knocking noises coming from the engine.
