A nasal cannula consists of a flexible tube that is placed under the nose. The tube includes two prongs that go inside the nostrils. A face mask covers the nose and mouth. Both methods of delivery attach to oxygen sources, which come in a variety of sizes.

Is an oxygen mask better than a cannula?

Apart from the physical differences of each device, the primary difference is that face masks allow higher concentrations and rates of flow of oxygen. A simple face mask can deliver oxygen concentrations from 40 to 60% at flow rates between 10 to 12LPM.

What percentage of oxygen is delivered by a simple face mask?

Simple masks deliver oxygen concentrations of between 40% and 60%. Flow rates for simple masks should not be below 5 L/min as the patient could easily breathe in air that has not been flushed from the mask.

What is the difference between nasal cannula and venturi mask?

The nasal cannula is a low flow system that mixes oxygen with room air. The flow rates range from 1 to 6 liters/minute, providing 24% to 44% of inspired oxygen. … The venturi or air-entrainment mask is a high flow device that delivers a fixed oxygen concentration of 24% to 50%.

When should a nasal cannula be used?

Nasal cannulas are used to deliver oxygen when a low flow, low or medium concentration is required, and the patient is in a stable state.

What are the disadvantages of nasal cannula?

Oxygen is generally provided via face masks and nasal cannula. Several drawbacks are associated with these devices, which may limit efficacy and tolerance of oxygen delivery. Usually, oxygen is not humidified at low flow, and complaints, especially dry nose, dry throat, and nasal pain, are common.

What is the difference between oxygen mask and nasal cannula?

A nasal cannula consists of a flexible tube that is placed under the nose. The tube includes two prongs that go inside the nostrils. A face mask covers the nose and mouth. Both methods of delivery attach to oxygen sources, which come in a variety of sizes.

Which oxygen mask is best?

• Non – Rebreather Masks. For patients who require sustained high-concentration oxygen therapy a non-rebreather mask is most suitable, providing the patient with valuable oxygen administration. …
• Nebuliser Masks. …
• Venturi Masks.

Which mask provides the highest concentration of oxygen?

Nasal cannulas and simple face masks are typically used to deliver low levels of oxygen. Another type of mask, the Venturi mask, delivers oxygen at higher levels. Sometimes nasal cannulas are also used to deliver high levels of oxygen.

What does 50% Venturi mask mean?

5. These masks are recommended when a fixed oxygen concentration is desired in patients whose ventilation is dependent on the hypoxic drive. … This means an oxygen flow of 2 L/min delivers a total flow of 50 L/min, well above the peak inspiratory flow rate. 7.

Article first time published on

How many Litres is 40 oxygen?

At 5 LPM, the approximate FiO2 is 40%.

How much oxygen does a high-flow nasal cannula deliver?

High-flow nasal cannula (HFNC) therapy is an oxygen supply system capable of delivering up to 100% humidified and heated oxygen at a flow rate of up to 60 liters per minute.

What is the difference between Venturi mask and oxygen mask?

One of the commonly used, conventional face masks for oxygen delivery is the ‘Venturi’ or air-entrainment system (1). While the Venturi mask is effective at delivering accurate oxygen concentrations (FiO2), it requires relatively high oxygen flow rates to achieve this.

Who needs a nasal cannula?

A nasal cannula is generally used wherever small amounts of supplemental oxygen are required, without rigid control of respiration, such as in oxygen therapy. Most cannulae can only provide oxygen at low flow rates—up to 5 litres per minute (L/min)—delivering an oxygen concentration of 28–44%.

Can a nasal cannula be used on a non breathing person?

A nasal cannula has no application in an emergency involving a non breathing person.

What does a nasal cannula do?

A nasal cannula is a medical device to provide supplemental oxygen therapy to people who have lower oxygen levels. There are two types of nasal cannulas: low flow and high flow. The device has two prongs and sits below the nose. The two prongs deliver oxygen directly into your nostrils.

What are different types of oxygen mask?

• Simple face mask.
• Non re-breather face mask (mask with oxygen reservoir bag and one-way valves which aims to prevent/reduce room air entrainment)
• Nasal prongs (low flow)
• Tracheostomy mask.
• Tracheostomy HME connector.
• Isolette – neonates (usually for use in the Neonatal Intensive Care Unit only)

What is the recommended oxygen flow l/min to COPD?

Oxygen therapy in the acute setting (in hospital) Therefore, give oxygen at 24% (via a Venturi mask) at 2-3 L/minute or at 28% (via Venturi mask, 4 L/minute) or nasal cannula at 1-2 L/minute. Aim for oxygen saturation 88-92% for patients with a history of COPD until arterial blood gases (ABGs) have been checked .

Do nasal cannula prongs go up or down?

Turn the cannula so the prongs are curved downward. Most cannulae today have curved prongs so they fit more naturally inside the nostrils. Hold the cannula so the prongs are pointing up toward the ceiling and curve down toward you.

What is the difference between HFNC and CPAP?

HFNC, like CPAP, is a high flow system and is able to generate a positive end expiratory pressure, but unlike CPAP it does not have a valve [9]. HFNC is suggested to reduce the upper airway dead space and resistance [10,11].

What is the difference between high flow oxygen and BiPAP?

Results showed that HFNC was not inferior to BiPAP in reintubation rates. Oxygenation was shown to improve more with BiPAP than HFNC but arterial carbon dioxide (PaCO2) was shown to decrease faster with HFNC. BiPAP did have higher rate of discontinuation of use and of skin breakdown.

What is the highest liter of oxygen you can be on?

Conventional low-flow devices (e.g., nasal cannula or simple face mask) provide 100% FiO2 at a maximum of 15 liters per minute. Even during quiet breathing, inspiratory flow rates are approximately 30 liters per minute, which exceeds supplemental oxygen flow (3).

How many liters of oxygen do you need for a Venturi mask?

Since the jets in venturi masks generally limit oxygen flow to 12 to 15 liters per minute, the total flow decreases as the ratio decreases.

Can COPD use non rebreather mask?

In severely hypoxemic patients with COPD, O2 may be delivered using a non-rebreathing mask with a target O2 flow rate of 10–15 L/min. Arterial blood gases must be analyzed regularly.

How many Litres is a non rebreather mask?

Non-rebreather face mask 10 – 15 Liters Per Minute. Pre-fill the reservoir on the mask prior to placing the mask on the patient.

How often should I change my oxygen nasal cannula?

As for the nasal cannula, if you are wearing your oxygen 7 days a week, 24 hours per day, the cannula should be changed every 2 weeks. You can wipe the nasal prongs during those two weeks with a clean cloth that has a mild soap solution, but that is all you need to do.

What does 15L of oxygen mean?

In regards to your question, the patient on 15L will be connected both to oxygen and to air. The combination of the oxygen flow rate (of 100% oxygen) and the air flow rate (of 21% oxygen) to a total of 15L/min will achieve the 30% of oxygen the patient is receiving. That is the basic relationship.

What is the difference between a Venturi mask and a non-rebreather?

A venturi mask is used when a fixed concentration of oxygen is needed. The non-rebreather mask is used mainly in emergency situations for acute respiratory conditions.

How do I know which Venturi mask to use?

1. BLUE = 2-4L/min = 24% O2.
2. WHITE = 4-6L/min = 28% O2.
3. YELLOW = 8-10L/min = 35% O2.
4. RED = 10-12L/min = 40% O2.
5. GREEN = 12-15L/min = 60% O2.

How can I increase my blood oxygen level?

You can increase the amount of oxygen in your blood naturally. Some ways include: Open windows or get outside to breathe fresh air. Something as simple as opening your windows or going for a short walk increases the amount of oxygen that your body brings in, which increases overall blood oxygen level.

Why is FiO2 important?

Clinical Significance The fraction of inspired oxygen, FiO2, is an estimation of the oxygen content a person inhales and is thus involved in gas exchange at the alveolar level. Understanding oxygen delivery and interpreting FiO2 values are imperative for the proper treatment of patients with hypoxemia.
