In short, the fundamental purpose of one of these traps is to use a column of condensate in such a way as to prevent air movement into or out of the equipment casing, while still allowing the condensate to drain away. An improperly constructed or missing trap can cause the following problems.

What is a condensate trap?

The condensate trap is a device inside a condensing boiler which collects water from the condensing process before it is expelled into the sewer via the condensate pipe. The purpose of the trap is to prevent toxic gases from entering the condensate pipe, and to manage the flow of condensate fluid out of the boiler.

Why do AC units have P traps?

The same thing applies to our air conditioner, but in our case, the purpose of the P-Trap is to prevent outside air from being drawn through the A/C unit. The weight of the water in the trap is enough to prevent this, while still allowing condensation to flow freely.

What is the function of the P-trap that is part of the condensate trap?

The P-trap traps solids that can clog the drain or sewer line. The P-trap stops sewer gases from backing into your home through the drain line.

How deep should the condensate drain trap be?

If a unit were to be operating at minus 6 inches WC maximum negative plenum pressure then the trap height, per the guidelines shown in Figure 1a, requires 7 + 3½ + 1½ + 1 inches of height from under the floor or about 13 inches below the floor level.

How does an air trap work?

An air trap is a filtering device intended to remove contaminants from a compressed air supply. The main function of an air trap is the removal of moisture and oil from compressed air, both of which are undesirable compression cycle byproducts.

Do all drains need a trap?

Because of its shape, the trap retains some water after the fixture’s use. This water creates an air seal that prevents sewer gas from passing from the drain pipes back into the building. Essentially all plumbing fixtures including sinks, bathtubs, and showers must be equipped with either an internal or external trap.

What does a boiler condensate pipe do?

The boiler condensate pipe is the pipe that allows this water to be drained from the heating system and disposed of with your household waste water.

Where is condensate trap on ideal boiler?

Locate the external condensate pipe area With an Ideal boiler, this is most likely going to be the thin, white plastic pipe that exits your house by the wall nearest to the boiler – note that the pipe won’t necessarily be white.

How do I know if my condensate pipe is clogged?

Signs that your condensate trap is blocked can include a faint gurgling noise coming from your boiler, or an unusual sound coming from the flue outside your home. If the trap does need to be cleaned, your heating engineer will remove it, rinse it out thoroughly, refill it and then refit it.

Article first time published on

What can block a condensate pipe?

In Winter, your condensate pipe may freeze and become blocked. This can easily be fixed by using a hot water bottle, or pouring warm water over the pipe itself.

Does washing machine drain need a trap?

When hooking up a new washing machine, some people look for a convenient drain line and simply install a pipe that extends to the washer. … The lack of a P-trap exposes the area to sewer fumes and the lack of venting will cause the drain to run sluggishly and overflow. Washers, like all fixtures, need a trap.

Why do you need a trap under your sink?

The p-trap under sink plumbing pipe serves the function of capturing a small amount of water inside your drainpipes after the sink is used. This plug prevents sewer gases from coming up the wastewater line and out the sink.

How far can a trap be from a drain?

According to the International Residential Code, the maximum vertical distance between the sink drain and the entrance to the p-trap is 24 inches.

What is an air trap?

Definition of air trap 1 : a device for shutting off foul air or gas from drains or sewers. 2 : air pocket.

How do steam condensate traps work?

Venturi steam traps operate by continuously removing condensate from the steam system. It allows any condensate present in the steam line to pass into the condensate return system as it is formed. The operation of the trap is based on the difference in density between water and steam.

What is the small pipe on the side of house dripping water?

The pan is drained by gravity, or is pumped out, through a small PVC pipe called the “condensate line” or “condensate drain.” A little clog in your condensate drain can create a huge problem!

Can you snake an AC drain line?

If you have a very stubborn clog that doesn’t come out with a shop vac and water, then you can try using a drain snake. Push the drain snake down into the drain line access near the air handler. Make sure the that the drain snake does not go towards your air handler or you could potentially damage the evaporator coil.

How much water should come out of AC drain line?

It’s completely normal for your AC to drain 5-20 gallons of water outside of your home (via the condensate drain). It’s NOT normal for your AC to drain any amount of water inside your home (around your indoor AC unit).

How do you solve common problems with condensate traps?

Depending on the type of trap in use, it can be blown dry with every cooling cycle leading to more problems inefficiency. The best way to resolve these problems is by contacting your HVAC technician to have the condensate drains cleaned and flushed.

Why is my boiler condensate pipe dripping?

This most commonly happens because of frozen water in the pipe, but it is possible to become blocked with debris as well. If it is frozen, you can probably thaw it out with some warm water. Don’t use boiling hot water as this may cause your pipe to develop a leak as mentioned above.

What does a boiler sump do?

The first is the sump at the bottom which collects the flue gas and also the liquid condensate all condensing boilers produce when running, develops a crack and a minor water leak. … This can be heard both inside the house, and outside in the street from the flue terminal.
