The tail of the weld symbol is the place for supplementary information on the weld. It may contain a reference to the welding process, the electrode, a detail drawing or any information that aids in the making of the weld that does not have its own special place on the symbol.

When should a welding symbol contain a tail?

There may be special instructions included in the tail of the welding symbol (see symbol 3). Generally this tells the welder to use a particular type of welding or to pay attention to a certain detail. If nothing is included in the tail, the tail is considered optional and can even be left off entirely.

Is it necessary to use a tail with the spot weld symbol?

The spot-weld symbol is centered on the reference line when there is no arrow side or other side significance. When the spot weld is used, the tail is optional. When the spot-weld symbol is centered on the reference line, the dimension can be placed on either side of the reference line.

What information can be added to a tail in a welding symbol?

A note in the tail of the welding symbol may be provided to specify which type of weld is required, a multiple reference line may be used to indicate the sequence of operation, or it may be specified in the welding procedure.

What is the purpose of welding symbols?

Weld symbols are used to indicate the welding processes used in metal joining operations, whether the weld is localized or “all around”, whether it is a shop or field weld, and the contour of welds.

What is FW in welding?

A resistance welding process that produces a weld at the interface of a butt joint by the heat produced during the flashing action and by the sudden application of high pressure after heating is substantially completed.

What is the difference between a weld symbol and a welding symbol?

There has been always confusion between a welding symbol and weld symbol. A Welding symbol is different from a weld symbol; which is a graphic character connected to the reference line of a welded symbol specifying the joint geometry. So basically, the weld symbol is a part of the welding symbol.

What is consumable insert in welding?

Consumable inserts are metal strips in special sizes and dimensions that are used for root pass welding with one side access.

What is a bevel weld?

Bevelling is the process of preparing metal to be welded, usually by cutting an angled slope on the edge of the metal. In pipe welding bevelling is an integral part of the engineering process. Two pipe ends due to be welded together have their shapes altered by removing some of the metal from each end.

What is a flare bevel weld?

What is Flare Bevel Groove weld? Flare bevel Groove Weld is type of a weld where a groove is formed between a joint member with a curved surface and another with a planar surface. … For example, a weld formed between a pipe and plate placed horizontally to each other as shown in below figure.

Article first time published on

What is symbols with no side significance?

The spot weld symbol is simply a circle that may be placed above, below, or centered on the reference line. When the symbol is centered on the reference line this indicates that there is no side significance.

What is RSW welding?

A resistance welding process that produces a spot weld at the faying surfaces of overlapped parts.

Is standard for welding symbols?

The internationally agreed standard for these symbols has been updated. … ISO 2553, Welding and allied processes – Symbolic representation on drawings – Welded joints, combines both systems and is the key industry International Standard for welding symbols.

What element of a welding symbol is the foundation from which the rest of the symbol is built and positioned?

The reference line becomes the foundation of the welding symbol. It is used to apply weld symbols, dimensions, and other data to the weld. The arrow simply connects the reference line to the joint or area to be welded. The direction of the arrow has no bearing on the significance of the reference line.

Which part of welding symbol indicates the position of the weld?

A fillet symbol features a triangular cross-section placed on the reference line. This indicates the position where the weld material will be placed and welded. The weld size is written to the left of the symbol, regardless of where the weld should be completed.

How do you draw welding symbols?

Any symbol that is used to show a joint or weld type feature on the other side of the arrow line is always placed on a dotted line. BS 499 and AWS require symbols to be placed above the reference line (which indicate the other side) or below the reference line (indicating the arrow side of the joint).

Where should the basic weld symbol be written in other side of the joint?

If a weld is to be placed on the other side of a joint a symbol will be placed above the reference line. If a weld is to be placed on the arrow side of a joint the symbol will be placed below the reference line.

What is the difference between weld and welding?

The weld symbol indicates the type of weld and, when used, is a part of the welding symbol. Welding Symbol: The welding symbol consists of several elements (see Figure). Only the reference line and arrow are required elements. Additional elements may be included to convey specific welding information.

What is FW and FFW?

FW = field weld. FFW = field-fit weld. A field-fit weld indicates that the designer has foreseen that the piping may need adjustment in the field so has added an extra length of pipe at a buttweld fitting or flange. The pipe end will be bevelled and welded on site after the installer determines the correct dimensions.

What is 6mm fillet weld?

Fillet welds are defined by the size of the leg length e.g. a 6 mm CFW is a continuous fillet weld having a leg length of 6 mm.

What is the purpose of the bevel?

A bevel is typically used to soften the edge of a piece for the sake of safety, wear resistance, or aesthetics; or to facilitate mating with another piece.

Why is it important to bevel the edges when making a butt weld?

In addition to yielding stronger welds, bevels make the welding process easier by increasing the visibility of the weld site. Bevels also provide depressions into which the molten flux can flow, making it easier to achieve attractive, straight, and uniform welds.

What is the difference between a consumable insert and a spacer?

A consumable insert symbol is used when an insert is used within a welded joint that becomes part of the weld. … A spacer may be used on a double groove weld. In this case both the top and bottom are prepped and a spacer is added to the middle of the groove. The symbol is a rectangle the breaks the reference line.

Which of the methods of applying weld metal only requires the welder to manipulate the welding gun?

In semiautomatic welding, defined as “manual welding with equipment that automatically controls one or more of the welding conditions,” the welder manipulates the welding gun to create the weld while the electrode is automatically fed to the arc.

What is bevel groove?

Is a weld that joins two pieces base metal—one piece with a square edge and another piece with beveled edge—together.

What is a groove weld symbol?

Like the basic fillet weld symbol, the groove weld symbol consists of a reference line, an arrow line, the tail, Weld Procedure Specification (WPS) information, and the appropriate groove weld symbol. Groove weld symbols can be much more complex than fillet welds symbols.

What are the four types of welding?

There are four main types of welding. MIG – Gas Metal Arc Welding (GMAW), TIG – Gas Tungsten Arc Welding (GTAW), Stick – Shielded Metal Arc Welding (SMAW) and Flux-cored – Flux-cored Arc Welding (FCAW). We dive deeper into each type of welding here.

When the weld symbol is placed below the reference line it shows that a weld is required only on the side of the joint?

When the weld symbol is placed below the reference line, it shows that a weld is needed only on the (arrow side); (other side) of the joint. 2. When the weld symbol is above the reference line, it indicates that a weld is wanted on the (arrow side); (other side); (both sides) of the joint. 3.

What is a staggered weld?

[′stag·ərd ‚in·tər′mit·ənt ′fil·ət ‚weld·iŋ] (metallurgy) Making a line of intermittent fillet welds on each side of a joint in a manner such that the increments on one side are not opposite to those on the other side.

What is typ in welding symbol?

The duplication of identical welding symbols on a drawing may be avoided by designating a single welding symbol as “TYPICAL” (abbreviated as “TYP”) and pointing the arrow to the representative joint. The drafter shall provide additional information to completely identify all applicable joints.

Why do spot welds fail?

Spot weld can fail in two completely distinct modes, namely, nugget pullout failure and interfacial failure. In this paper, we show that the nugget pullout failure is caused by plastic collapse and the interfacial failure is governed by crack or fracture mechanics.
